Insulation Enhancement Systems Subcategory

Heat-Shrinkable Busbar Insulation Tubing - BBIT

Raysulate Busbar Insulation Tubing. Non-halogen busbar insulation up to 36 kV, Ø 11-125 mm. 6 part codes, Rs 3,390 - 18,150 per meter.

Rs 3,390 - 18,150

Heat-Shrinkable Busbar Insulation Tubing - BBIT is a Busbar Insulation Tubing from Raysulate (Raychem RPG). 6 part codes, list price Rs 3,390 - 18,150 per meter, effective 01-04-2026, exclusive of taxes. Jai Enterprises supplies it across India from Bhilai and Raipur, Chhattisgarh - call +91 7300249139 or email support@jaient.in.

BBIT heat-shrinkable busbar insulation tubing delivers insulation and anti-tracking protection for busbars on systems up to 36 kV, covering application diameters from 11 mm to 125 mm.

Specifications

Brand	Raysulate (Raychem RPG)
Product range	Busbar Insulation Tubing
Model	BBIT
Part codes listed	6
List price	Rs 3,390 - 18,150 per meter, effective 01-04-2026, exclusive of GST
Supplied by	Jai Enterprises, Bhilai and Raipur - across India

Key Features

Suitable for voltage up to 36 kV, application Ø 11-125 mm
Excellent flexibility - can be installed on a wide range of curved or bent busbars without cracking or creasing
Exceptional insulation and long term reliability even at high continuous operating temperature
Good thermal emissivity and contact with busbars means no derating is required
Excellent anti-tracking properties
Flame retardant and non-halogen based material

Ordering Information

Size Expanded/Recovered (mm)	Rectangular bars Ø L+T (mm)	Round bars Ø D (mm)	Roll Length (m)	Part Code (PCN)	List Price (INR)
25/10	17-18	11-20	25	AAA9000006	3,390
40/16	28-45	18-32	20	JAA0090322	4,010
65/25	44-69	28-47	15	JAA0090323	4,220
100/40	69-102	44-72	15	JAA0090320	6,340
150/60	102-148	65-105	15	JAA0090002	10,150
175/80	133-196	85-125	10	JAA0090321	18,150

Applications

Used in Power and Network, Utility, Oil and Gas Petrochemical, Railways, Automation and Process Control, Cement Industry, Metal Industry.

Frequently Asked Questions

How do I choose the right size of Heat-Shrinkable Busbar Insulation Tubing for my busbar?

Measure the bar first, then pick the part code whose range covers it — rectangular bars are quoted as L+T, covering 17 to 196 mm; round bars by diameter, covering 11 to 125 mm. The tubing is supplied expanded and recovers onto the bar, so the bar must sit inside the range: too large and the tube will not pass over it, too small and it will not grip.

What does Heat-Shrinkable Busbar Insulation Tubing - BBIT cost?

List prices run from Rs 3,390 to Rs 18,150 per meter, effective 01-04-2026, exclusive of GST, freight and installation. Project quantities are quoted against the list.

What is the lead time and is it available from stock?

Fast-moving part codes are usually available from stock in Bhilai and Raipur; the rest are called off against Raychem RPG lead times. Call +91 7300249139 or email support@jaient.in with the part code and quantity and we will confirm availability the same working day.

Who supplies Heat-Shrinkable Busbar Insulation Tubing - BBIT in India?

Jai Enterprises is a Raysulate / Raychem RPG distributor supplying Busbar Insulation Tubing across India from Bhilai and Raipur, Chhattisgarh. We support selection, pricing and documentation — call +91 7300249139 or email support@jaient.in.

Raysulate / Raychem RPG list prices in INR, effective 01-04-2026, exclusive of taxes. Catalogue page 2.
