Waterproof Insulation Piercing Connectors (IPC)
Raychem RPG Insulation Piercing Connectors. 9 part codes, Rs 125 - 1,030 per unit.
Rs 125 - 1,030
Waterproof Insulation Piercing Connectors (IPC) is an Insulation Piercing connector from Raychem RPG. It covers cable sizes 1.5 - 150 sq mm. 9 part codes, list price Rs 125 - 1,030 per unit, effective 01-04-2026, exclusive of taxes. Jai Enterprises supplies it across India from Bhilai and Raipur, Chhattisgarh - call +91 7300249139 or email support@jaient.in.
Waterproof Insulation Piercing Connectors (IPC) from the Raychem RPG Connectors & Fittings For LV ABC range.
Specifications
| Brand | Raychem RPG |
|---|---|
| Product range | Insulation Piercing Connectors |
| Model | IPC |
| Cable size range | 1.5 - 150 sq mm |
| Conforms to | NFC 33020, EN 50483-4 |
| Part codes listed | 9 |
| List price | Rs 125 - 1,030 per unit, effective 01-04-2026, exclusive of GST |
| Supplied by | Jai Enterprises, Bhilai and Raipur - across India |
Key Features
- Conforms to NFC 33-020 and EN 50483-4 Standards
- Components are not losable, end cap attached to body
- Insulation material made of weather and UV resistant glass fibre reinforced polymer
- Contact plates made of aluminium or copper, bolt made of steel with Geomet (Chromium free) protection
Ordering Information
| Cable Size (sq. mm) | Blade Material | Part Code (PCN) | List Price (INR) |
|---|---|---|---|
| 4-50 | Aluminium | AJA4040169 | 200 |
| 16- 95 | Aluminium | AJA4040177 | 345 |
| 6-50 | Aluminium | AJA4040176 | 185 |
| 35-150 | Aluminium | AJA4040114 | 415 |
| 1.5-10 | Aluminium | AJA4040115 | 175 |
| 6-25 | Aluminium | AJA4040331 | 125 |
| 4-50 | Tin plated Copper | AJA4040458 | 410 |
| 16-95 | Tin plated Copper | AJA4040457 | 1,030 |
| 35-150 | Tin plated Copper | AJA4040217 | 995 |
Applications
Used in Commercial, Power and Network, Utility, Railways.
Related products
- Deep Drawn Box for LV ABC — also in Connectors & Fittings for LV ABC
- Anchor Clamp for LV ABC Insulated Messenger — also in Connectors & Fittings for LV ABC
- Anchor Clamp for LV ABC — also in Connectors & Fittings for LV ABC
Frequently Asked Questions
How do I choose the right Waterproof Insulation Piercing Connectors (IPC) for my cable?
Match the conductor cross-section to the range in the ordering table — the sizes here run from 1.5 to 150 sq mm. Each size has its own part code; order the one whose range brackets your cable.
Which standards does this product conform to?
It is manufactured and tested to NFC 33-020, EN 50483-4. Test certificates can be supplied with the order on request.
What does Waterproof Insulation Piercing Connectors (IPC) cost?
List prices run from Rs 125 to Rs 1,030 per unit, effective 01-04-2026, exclusive of GST, freight and installation. Project quantities are quoted against the list.
What is the lead time and is it available from stock?
Fast-moving part codes are usually available from stock in Bhilai and Raipur; the rest are called off against Raychem RPG lead times. Call +91 7300249139 or email support@jaient.in with the part code and quantity and we will confirm availability the same working day.
Who supplies Waterproof Insulation Piercing Connectors (IPC) in India?
Jai Enterprises is a Raychem RPG distributor supplying Insulation Piercing Connectors across India from Bhilai and Raipur, Chhattisgarh. We support selection, pricing and documentation — call +91 7300249139 or email support@jaient.in.
Raychem RPG list prices in INR, effective 01-04-2026, exclusive of taxes. Catalogue page 56.
Applications
Availability: Enquiry-based — contact us for stock and lead time.
